Tensioner for live-line cables
Tensioner for live-line cables
Tensioner for live-line cables. Tensioner for AC and ACC cables, manufactured in galvanized carbon steel; used for tensioning conductors, in the construction and maintenance of overhead distribution lines, electrical transmission, as well as in telecommunication lines.
Models
Especificações
Models
| Reference | Description |
| TM01120101 | Tensioner for live line cable, conductor 5,08 mm X 10,16 mm |
| TM01120102 | Tensioner for live line cable, conductor 7,87 mm X 13,50 mm |
| TM01120103 | Tensioner for live line cable, conductor 13,41 mm X 18,80 mm |
| TM01120104 | Tensioner for live line cable, conductor 18,80 mm X 21,80 mm |
Especificações
| Reference | Conductor Ø Minimum / Maximum (mm) | Nominal working capacity (daN) | Jaw Type/Material | Approx. Weight | ||
| Working (daN) | Breaking (daN) | Kg | lb | |||
| TM01120101 | 5,08/10,16 | 800 | 2000 | DC type made of Bronze | 1,48 | 3,26 |
| TM01120102 | 7,87/3,50 | 800 | 2000 | DC type made of Bronze | 1,90 | 4,19 |
| TM01120103 | 13,41/18,80 | 1700 | 3600 | DC type made of Bronze | 3,50 | 7,72 |
| TM01120104 | 18,80/21,80 | 1700 | 3600 | DC type made of Bronze | 3,50 | 7,72 |
