Rotating ladder
Rotating ladder
Rotating ladder from Tecmarques is equipment intended for operations on electrical distribution networks, public lighting and other services, offering safety and high performance. A structure mounted on a tilting support with rotation capacity, built in structural steel. Composed of two ladder sections, one fixed and the other extendable.
Models
Especificações
Características Principais
Models
| Reference | Description |
| TM06130401 | Rotating ladder |
Especificações
| Working Angle | Nominal Working Capacity | Maximum Height of the last rung | |
| Kg | m | ft | |
| 64° | 110 (243 lb) | 7,50 | 24,60 |
| 68° | 7,60 | 24,90 | |
| 72° | 7,80 | 25,60 | |
| 76° | 8,02 | 26,30 | |
| 80° | 8,06 | 26,44 |
Características Principais
| Equipment type | Non-insulated (for work on energized networks up to 1000 V) | |
| Tilting operation | Assisted by helical spring and counterweight | |
| Rotation and extension | Manual operation | |
| Safety locks | In all working and transport positions | |
| Rotation column | Infinite | |
| Minimum vehicle load capacity | 1000 kg (2204 lb) | |
| Minimum internal body dimensions | Length 600 mm | Width 600 mm | |
| Approx. equipment weight | 350 kg (770 lb) |
