Protected cable. Highly flexible, even at cold temperatures, this cable has combinations of coatings and insulation that are resistant to abrasion, oil, heat, moisture and ozone. The distinctive color is derived from the EPR (ethylene-propylene) coating. To facilitate identification and classification, the voltage and gauge (in AWG) are marked along the entire length of the cable at regular intervals. The conductor is formed by super flexible copper filaments. Ideal for various applications due to its combinations of coatings and insulation that are resistant to abrasion, oil, heat, moisture and ozone. Its distinctive color, coming from the EPR (ethylene-propylene) coating, facilitates visual identification. For greater ease in identification and classification, the voltage and gauge (in AWG) are marked along the entire length of the cable at regular intervals. The conductor, composed of highly flexible copper filaments, ensures excellent electrical conduction.
| Reference | Description |
| TM05010101 | Protected cable |
| TM05010102 | Protected cable |
| TM05010103 | Protected cable |
| TM05010104 | Protected cable |
| TM05010105 | Protected cable |
| Reference | Rated voltage (kV) | Nominal Section (mm²) | Cable Gauge (AWG) | Nominal Ø of Copper Conductor (mm) | Maximum Current Capacity (A) | Approx. Weight Kg | Approx. Weight lb |
| TM05010101 | 15 | 35 | 2 | 8 | 250 | 0,77 | 1,70 |
| TM05010102 | 15 | 50 | 1/0 | 10 | 250 | 1,40 | 3,09 |
| TM05010103 | 35 | 50 | 1/0 | 10 | 250 | 1,70 | 3,75 |
| TM05010104 | 15 | 70 | 2/0 | 12 | 300 | 1,70 | 3,75 |
| TM05010105 | 15 | 95 | 4/0 | 15 | 400 | 2,35 | 5,18 |
| Reference | Description |
| TM05010101 | Protected cable |
| TM05010102 | Protected cable |
| TM05010103 | Protected cable |
| TM05010104 | Protected cable |
| TM05010105 | Protected cable |
| Reference | Rated voltage (kV) | Nominal Section (mm²) | Cable Gauge (AWG) | Nominal Ø of Copper Conductor (mm) | Maximum Current Capacity (A) | Approx. Weight Kg | Approx. Weight lb |
| TM05010101 | 15 | 35 | 2 | 8 | 250 | 0,77 | 1,70 |
| TM05010102 | 15 | 50 | 1/0 | 10 | 250 | 1,40 | 3,09 |
| TM05010103 | 35 | 50 | 1/0 | 10 | 250 | 1,70 | 3,75 |
| TM05010104 | 15 | 70 | 2/0 | 12 | 300 | 1,70 | 3,75 |
| TM05010105 | 15 | 95 | 4/0 | 15 | 400 | 2,35 | 5,18 |
