Extension Ladder with Double Stringer
Extension Ladder with Double Stringer
Extension Ladder with Double Stringer. The Double Stringer Ladder from TECMARQUES, is made of fiberglass impregnated with epoxy resin. The ladder has a rest handle with rubber coating, providing better fixation during the execution of services, and a mobile shoe for better use on uneven terrain. This ladder is developed to assist in interventions on energized networks up to 500 kV.
Models
Especificações
Models
| Reference | Description |
| TM06040101 | Simple double-stringer ladder – Nominal length 2800mm – Rungs 8 |
| TM06040103 | Simple double-stringer ladder – Nominal length 4600mm – Rungs 14 |
| TM06040102 | Simple double-stringer ladder – Nominal length 3700mm – Rungs 11 |
| TM06040104 | Simple double-stringer ladder – Nominal length 5900mm – Rungs 18 |
Especificações
| Reference | Nominal Length (mm) | Number of steps | Approx. Weight | |
| Kg | lb | |||
| TM06040101 | 2800 | 8 | 11,00 | 24,25 |
| TM06040103 | 4600 | 11 | 14,00 | 30,86 |
| TM06040102 | 3700 | 14 | 20,00 | 44,09 |
| TM06040104 | 5900 | 18 | 21,00 | 46,30 |
| Reference | Description |
| TM06040101 | Simple double-stringer ladder – Nominal length 2800mm – Rungs 8 |
| TM06040103 | Simple double-stringer ladder – Nominal length 4600mm – Rungs 14 |
| TM06040102 | Simple double-stringer ladder – Nominal length 3700mm – Rungs 11 |
| TM06040104 | Simple double-stringer ladder – Nominal length 5900mm – Rungs 18 |
| Reference | Nominal Length (mm) | Number of steps | Approx. Weight | |
| Kg | lb | |||
| TM06040101 | 2800 | 8 | 11,00 | 24,25 |
| TM06040103 | 4600 | 11 | 14,00 | 30,86 |
| TM06040102 | 3700 | 14 | 20,00 | 44,09 |
| TM06040104 | 5900 | 18 | 21,00 | 46,30 |
